•Product Features
Adopts LED light source with long service life and cost‑saving; can be freely combined according to actual size requirements, greatly expanding application scope; extremely simple circuit connection for backlight module, power‑on available just by connecting screws.
•Structure & Process
Module housing material: PVC; freely spliceable and combinable according to actual light‑box dimension; screw‑locking wiring method.
•Electrical Performance
Input voltage DC12V; max power per piece 1.5W; CCT 2700‑7000K; beam angle 120°; luminous flux 100Lm; light decay ＜5%@1000h.
•Working Environment
Operating temperature ‑20℃~+50℃, storage temperature ‑20℃~+60℃; long service life, compliant with RoHS directive.
•Application Scenarios
LED backlight module delivers perfect solution for large‑size ultra‑thin light boxes, easy for installation; suitable for indoor & outdoor large‑scale media advertising light boxes in metro, airport, tunnel, high‑speed railway and station; it also provides backlight effect for commercial & office lighting products, which is an ideal option for large light boxes and commercial office lighting.
