Magnetic Mini Spot Light
- Model：
- WF-JSD29D-1W-12V
- Input voltage：
- DC12V
- IP Rating：
- IP42
- Certifications：
- —
- Features：
- This is a DC12V aluminum alloy mini spotlight with 30° beam angle, high CRI＞90, customizable color temperature and IP42 protection rating. It is suitable for local accent lighting for bookcases, display cabinets, kitchen cabinets and other furniture.
Product Features
Aluminum alloy housing, default iron-grey finish with customizable color, 30° focused beam angle, controlled by external switch; DC12V low voltage power supply, single 2835 SMD LED, 1W power; High CRI＞90 for excellent color rendering; CCT 2700–6500K customizable, IP42 rated, light decay ＜5% after 20000 hours, stable brightness for long-term use.
Aluminum alloy housing, default iron-grey finish with customizable color, 30° focused beam angle, controlled by external switch; DC12V low voltage power supply, single 2835 SMD LED, 1W power; High CRI＞90 for excellent color rendering; CCT 2700–6500K customizable, IP42 rated, light decay ＜5% after 20000 hours, stable brightness for long-term use.
Structure & Process
Aluminum alloy housing, default iron-grey, custom color available, external switch control, IP42 protection, light decay ＜5%@20000h.
Aluminum alloy housing, default iron-grey, custom color available, external switch control, IP42 protection, light decay ＜5%@20000h.
Optical & Electrical Specifications
DC12V low voltage supply, power 1W, equipped with one 2835 SMD LED, beam angle 30°, CRI＞90, luminous flux 70Lm±5%, customizable CCT 2700–6500K, light decay＜5% after 20000 hours.
DC12V low voltage supply, power 1W, equipped with one 2835 SMD LED, beam angle 30°, CRI＞90, luminous flux 70Lm±5%, customizable CCT 2700–6500K, light decay＜5% after 20000 hours.
Operating Environment
Operating temperature: -25℃ ~ +45℃; Storage temperature: -20℃ ~ +60℃.
Operating temperature: -25℃ ~ +45℃; Storage temperature: -20℃ ~ +60℃.
Application
Accent lighting for furniture such as bookcases, display cabinets and kitchen cabinets.
Accent lighting for furniture such as bookcases, display cabinets and kitchen cabinets.
| Category | Parameter Item | Value |
| Appearance & Structure | Model | WF-JSD29D-1W-12V |
| Material | Aluminum Alloy | |
| Color | Default Iron-Grey (Customizable) | |
| Switch Type | External Switch | |
| Electrical Parameters | Input Voltage | DC12V |
| Power | 1W | |
| LED Type | 2835 SMD | |
| LED Quantity | 1PCS | |
| Optical Parameters | Beam Angle | 30° |
| CCT Range | 2700K‑6500K (Customizable) | |
| Luminous Flux | 70Lm±5% | |
| CRI | CRI＞90 | |
| Light Decay | ＜5%@20000h | |
| Others | IP Rating | IP42 |
| Operating Temp. | -25℃～+45℃ | |
| Storage Temp. | -20℃～+60℃ |
Note: Actual values vary with color temperature and other factors. Refer to the test report for final data.
