Anti-Glare Spotlight
- Model：
- WF-JSD4226
- Input voltage：
- DC12V
- IP Rating：
- IP54
- Certifications：
- —
- Features：
- This is a DC12V aluminum anti-glare spotlight. Power rating 1.2W per piece, high CRI Ra≥90, color temperature optional from 2700K to 6500K, IP54 rated. It features low light decay and is suitable for accent indoor lighting in homes, offices, shop windows and other commercial spaces.
Product Features
Aluminum alloy housing with focused anti-glare optical design, controlled by external switch; DC12V low voltage input, 1.2W per light; CRI Ra≥90 for excellent color rendering; CCT 2700–6500K optional; IP54 dust and splash resistant, low light decay, RoHS compliant, stable and reliable performance.
Aluminum alloy housing with focused anti-glare optical design, controlled by external switch; DC12V low voltage input, 1.2W per light; CRI Ra≥90 for excellent color rendering; CCT 2700–6500K optional; IP54 dust and splash resistant, low light decay, RoHS compliant, stable and reliable performance.
Structure & Process
Compact mini aluminum alloy housing, external switch control, IP54 protection, light decay ＜5%@1000h.
Compact mini aluminum alloy housing, external switch control, IP54 protection, light decay ＜5%@1000h.
Optical & Electrical Specifications
DC12V low voltage supply, 1.2W per light, single LED chip, high CRI Ra≥90, luminous flux 85Lm (±10%), customizable CCT 2700–6500K, light decay＜5% after 1000 hours operation.
DC12V low voltage supply, 1.2W per light, single LED chip, high CRI Ra≥90, luminous flux 85Lm (±10%), customizable CCT 2700–6500K, light decay＜5% after 1000 hours operation.
Operating Environment
Operating temperature: -20℃ ~ +40℃; Storage temperature: -20℃ ~ +60℃. Compliant with RoHS directive.
Operating temperature: -20℃ ~ +40℃; Storage temperature: -20℃ ~ +60℃. Compliant with RoHS directive.
Application
Indoor lighting for homes and offices; accent lighting for displays in shopping malls and retail store windows.
Indoor lighting for homes and offices; accent lighting for displays in shopping malls and retail store windows.
| Category | Parameter Item | Value |
| Appearance & Structure | Model | WF-JSD4226-0130-12V-T |
| Material | Aluminum Alloy (AL) | |
| Switch Type | External Switch | |
| Electrical | Input Voltage | DC12V |
| Power | 1.2W | |
| LED Quantity | 1PCS | |
| Optical | CCT Range | 2700K‑6500K (customizable) |
| Luminous Flux | 85Lm(±10%) | |
| CRI | RA≥90 | |
| Light Decay | ＜5%@1000h | |
| Others | IP Rating | IP54 |
| Certification | RoHS | |
| Operating Temp. | -20℃～+40℃ | |
| Storage Temp. | -20℃～+60℃ |
Note: Actual values vary with color temperature and other factors. Refer to the test report for final data.
