• Product Features

External independent type, constant‑voltage output; Compact, ultra‑thin and lightweight; Wide input voltage 100‑240VAC (50/60Hz); Ultra‑low standby power ≤75mW; Max conversion efficiency ≥88%; Isolation design; Multi‑port output; PC fire‑resistant housing; Built‑in active PFC; Complete protection against short‑circuit, overload, over‑voltage and over‑temperature; Support Bluetooth‑Mesh wireless group‑link, suitable for indoor 12/24V constant‑voltage LED lamps.

• Structure & Process

PC fire‑resistant housing, ultra‑thin compact structure; External independent mounting, isolated architecture with built‑in active PFC; Equipped with 4‑pin Dupont terminal +1 high‑current terminal for output; 2 controller ports on side (compatible with door‑switch, hand‑wave, touch, PIR motion sensors). This power supply belongs to wireless group‑link series. Bluetooth‑Mesh builds dynamically expandable network. Multiple power supplies communicate with wireless switches via Bluetooth, max communication distance up to 30M. Realize long‑distance wiring‑free centralized management for LED fixtures, compatible with wireless sensor switches. Dimension:160×62×19.5mm(L×W×H).

• Electrical Performance

 Input:AC100‑240V 50/60Hz; Constant‑voltage output DC12V/DC24V; Full‑load efficiency≥90%; Standby power ≤75mW; PF≥0.95@115VAC; PF≥0.90@230VAC; THD＜10%; Output voltage accuracy ±2.5%; Ripple:12V≤120mVp‑p,24V≤240mVp‑p; Rise time ≤0.5S; IP20; Short‑circuit / over‑current / over‑temperature protection, auto‑recovery after fault removal. Max case temperature Tc≤+85℃.

• Working Environment

 Operating temperature‑20℃~+40℃; Storage temperature‑20℃~+60℃; Working humidity 20‑95%RH non‑condensing; Natural air cooling.

• Application

Driving for indoor 12V/24V constant‑voltage LED lights, such as cabinet light, linear light, LED strip. Support Bluetooth‑Mesh wiring‑free centralized control.

Category	Item	Parameter
Product Info	Model	Constant‑voltage LED Driver (DC12V / DC24V optional)
	Dimension	160×62×19.5mm(L×W×H)
	Material	PC fire‑resistant plastic
	Mounting	External independent installation
	Structure Feature	Isolation design, built‑in active PFC, multi‑port output, Bluetooth‑Mesh wireless group‑link, 2 side controller ports
Electrical Performance	Input Voltage	100‑240VAC,50/60Hz
	Output Voltage	DC12V / DC24V (Constant‑voltage)
	Efficiency	≥90%
	Power Factor	PF≥0.95@115VAC; PF≥0.90@230VAC(Full load)
	THD	THD＜10%(Full load @115VAC,230VAC)
	Standby Power	≤75mW
	Output Voltage Accuracy	±2.5%
	Ripple & Noise	12V≤120mVp‑p;24V≤240mVp‑p
	Rise Time	≤0.5S
Protection	Over‑current	Protection triggers at 110%‑130% load, auto‑recovery after normal load
	Short‑circuit	Auto‑recovery after fault removal
	Over‑temperature	Output cut‑off; auto‑restart after temperature drops
Environment	Operating Temp	‑20℃~+40℃
	Max Case Temp	Tc=+85℃
	Working Humidity	20~95%RH,non‑condensing
	Storage Temp & Humidity	‑20~+60℃,10~95%RH,non‑condensing
Safety & EMC	Safety Standard	UL8750,EN61347,GB17625 etc.
	EMC	Comply with corresponding EMC emission & immunity standards
