Outline drawing

• Dimensions(mm)Custom sizes available on request unit:mm

Features

• Low energy consumption, eco-friendly, long service life
• Soft luminance, stable performance
• In-cabinet Illuminating
• Low-voltage operation, safe and reliable
• :3M

Product introduction

This product is a LEDCabinetLight,Cabinet,Showcase,Use.

Specifications

• Actual values vary with CCT etc.; data subject to test report

Model:WF-LT2610C-6028-12V

Material

AL+Silicone

Color

,,,

25.5*10.3*L(Length customizable)

Voltage

DC12V

Power(Max)

10W/M

LEDModel

2835

LEDQuantity

120Pcs/M

Beam angle

120°

CCT

2700-6500K

Luminous flux

100LM/M±10%

RA≥80

Lumen maintenance

<5%@1000h

Other

-20℃~+50℃

Storage temperature

-20℃~+60℃

IP rating

IP20

Lifetime

＞20000hrs
