• Product Features
Made of high‑quality aluminum with excellent heat dissipation performance. Anodized surface treatment for anti‑fading effect. Ultra‑thin and lightweight body with thickness only 11.5 mm, saving cabinet installation space. Equipped with intelligent door‑control sensor, automatically switches working mode with door opening/closing. UV sterilization activates automatically for 30 minutes when door is closed, easy and worry‑free to use.
• Structure & Process
Overall dimension: 400 x 45 x 11.5mm; Material: AL+PC+PMMA; Ingress protection: IP20; Service life＞20000hrs; Luminous attenuation＜5%@1000h.
• Optical & Electrical Performance
Power supply: DC12V, Max power MAX 6W. White light section: 72pcs 3014 LED beads; Color temperature 2700‑6500K; Luminous flux 210‑250Lm; CRI RA≥90. UV sterilization section: 5pcs 3535 (UVA+UVC) LED beads; UVA wavelength 395‑405nm, UVC wavelength 260‑280nm.
• Working Environment
Operating temperature ‑20℃～+40℃, storage temperature ‑20℃～+60℃.
• Application Scenarios
Suitable for cabinets, dish cabinets, disinfection cabinets and other cabinet‑type equipment, meets requirements for daily lighting and UV sterilization & disinfection.
| Category | Item | Value |
|---|---|---|
| Basic Info | Dimension | 400 x 45 x 11.5 mm |
| Material | AL+PC+PMMA | |
| White Light Params | LED Model | 3014 |
| LED Qty | 72 | |
| Color Temp | 2700k‑6500k | |
| Luminous Flux | 210‑250Lm | |
| CRI | RA≥90 | |
| UV Params | LED Model | 3535(UVA+UVC) |
| LED Qty | 5 | |
| Wavelength | 395‑405nm(UVA) / 260‑280nm(UVC) | |
| Electrical | Power | MAX 6W |
| Power Supply | DC12V | |
| Environment & Lifetime | Operating Temp | ‑20℃～+40℃ |
| Storage Temp | ‑20℃～+60℃ | |
| Lifetime | ＞20000hrs | |
| Luminous Attenuation | ＜5%@1000h | |
| IP Rating | IP20 |
