10×10mm Side-Emitting Silicone LED Light
- Model：
- WF-SDRT1010S2-6028WW-12V
- Input voltage：
- 12V
- IP Rating：
- IP67
- Certifications：
- Features：
- This silicone LED strip features one-piece molding, 120° wide-angle uniform illumination with no dark zones, IP67 waterproof/dustproof/saltwater-resistant rating, safe DC12V low-voltage power supply, flexible 25mm cut intervals, and CE/RoHS certification — ideal for furniture, display cabinet, and outdoor decorative lighting.
Product Features
Adopts one-piece silicone molding process with a 120° large light-emitting surface for wide-angle uniform illumination without dark zones; IP67 waterproof and dustproof with a smooth, easy-to-clean surface, saltwater-resistant and UV-resistant; powered by safe DC12V low voltage with a minimum cut length of 25mm for flexible and convenient installation; CE and RoHS certified for reliable and guaranteed quality.
Optical Performance
120° wide-angle uniform illumination with no dark zones, soft and natural light color for outstanding visual effects, suitable for various decorative lighting scenarios.
Protection Performance
IP67 full-protection design with a smooth and easy-to-clean strip surface, waterproof and dustproof, resistant to saltwater corrosion and UV radiation, suitable for outdoor and humid environments.
Electrical Performance
Driven by safe DC12V low voltage for reliable and safe use; minimum cut length of 25mm allows flexible customization as needed, with convenient wiring and installation.
Structure & Application
Seamless flexible silicone molding that can be bent into various shapes, CE and RoHS certified to meet international environmental and safety standards, widely applicable to furniture, display cabinets, cabinets, and outdoor decorative lighting
| Category | Parameter Name | Parameter Value |
| Appearance Structure | Product Specification | 25(W)×13.5(H)×Length(L) mm |
| Material | PC | |
| Electrical Parameters | Input Voltage | DC12V |
| Power | MAX 10W/M(Customizable) | |
| Beam Angle | 120° | |
| Color Temperature Range | 2700K-6500K | |
| Luminous Flux | 560(±10%)Lm/M | |
| CRI | RA≥90 | |
| Lumen Depreciation | ≤5%1000h | |
| IP Rating | IP65 | |
| Other | Warranty | 20000hrs |
| Operating Temperature | -20℃~+40℃ | |
| Storage Temperature | -20℃~+60℃ | |
| RoHS Directive | (EU) 2015/863 |
