•Product Features

Made of silicone material with IP65 protection grade; soft and uniform glare-free lighting; built-in IC LEDs support various dynamic colorful lighting effects when matched with controllers.

•Structure & Process

Adopts single-lamp cutting design with high cutting accuracy and a minimum cutting size of 6.95mm; flexible and durable structure with waterproof and dustproof performance, suitable for special-shaped installation.

•Application Scenarios

Widely used for edge trimming, advertising signs, 3D luminous characters, signage, light boxes, and various indoor and outdoor decorative lighting applications.

Category	Parameter	WF-SRDT0410T-7220PX-12V-T
Appearance structure	Product specification	4 (W) ×10 (H) ×Length (L) mm
	Retaining clip	21.25.99.6mm(optional)
	Screws	M2.2*8mm(optional)
Electrical parameter	Input voltage	DC12V(±5%)
	Electricity	MAX 700mA/M
	Power	MAX 8.4W/M
Optical properties	Beam angle	120°
	Light decay rate	<5%@1000h
Other	Single-piece inner packaging	Electrostatic bags
	Class of protection	IP65
	Quality guarantee	20000hrs
	Operating temperature	-20℃～+40℃
	Storage temperature	-20℃～+60℃
	RoHS Directive	(EU) 2015/863
